King Air Flap Roller Kit

Marsh Brothers Aviation’s Flap Roller upgrade kit is a proactive solution that eliminates flap roller bearing seizure and minimizes wear of the aircraft flap tracks. By eliminating the roller greasing requirement via use of a self-lubricating bearing system, the rollers are maintenance-free by design thereby increasing the mean time between maintenance while reducing overall costs associated with replacement and repair of flap system components.

• Reduces unscheduled maintenance downtime and expense.
• Eliminate the risks associated with bearing seizure and costs associated with flap track replacement.
• No hot/cold grease implications on bearing operation. Bearing is self-lubricating, requires no grease.
• Cartridge-type bearing design is highly resistant to incursion by dust/debris.
• Easy to install: Drop-in solution reduces part count and needing to stack-up parts on assembly.

The bearing components are manufactured from AeroTough® GF, a proprietary engineered thermoplastic material which provides self-lubrication and can operate through a wide range of temperatures.

• Approved for installation in Canadian Registered aircraft by Transport Canada Supplemental Type Certificate No.  SA21-5 and US Registered aircraft by FAA Supplemental Type Certificate SA11855IB, and Brazilian Registered aircraft by ANAC Supplemental Type Certificate 2024S08-04.

• TC Supplemental Type Certificate
• FAA Supplemental Type Certificate
• ANAC Supplemental Type Certificate 2024S11-02 (Portuguese)
• ANAC Approved Models List (Portuguese)

Refer to ANAC Approved Models List

King Air 200

King Air 300

Marsh Brothers Aviation Inc. (MBA) shall not be liable under any circumstances, for any loss of profits or any other contingent, consequential, or special damages if the buyer repairs, replaces, or installs products that are purchased from unauthorized sellers and deviates from the manufacturer’s specifications concerning use, maintenance, repair, alterations and modifications.
